Product Description

RS-380 RS-385 Micro 380 DC Motor 12V~24V 13000RPM High Speed Large Torque for Electric Drill Garden Tools Toy Model
RS-380 RS-385 Micro 380 DC Motor 12V~24V 13000RPM High Speed Large Torque for Electric Drill Garden Tools Toy Model
Product Description

RS-380 RS-385 Micro 380 DC Motor 12V~24V 13000RPM High Speed Large Torque for Electric Drill Garden Tools Toy Model

Product Details
RS-380 RS-385 Micro 380 DC Motor 12V~24V 13000RPM High Speed Large Torque for Electric Drill Garden Tools Toy Model

Motor Customized Specification, Please contact me.

Reference Drawing

------ RS - 365

RS-365 Drawing

------ RS - 385

RS-385 Drawing

------ RS - 395

RS-395 Drawing

The length of shaft can be customized, Please contact me.

Reference Datasheet
PMDC MOTOR Technical Data
Model Rated Voltage (V) No-Load Rated Stall
Operating Range Nominal Speed Current Speed Current Torque Power Current Torque
RPM A RPM A mN.m / gf.cm W A mN.m / gf.cm
RS-390SH 20156R 6.0~12.0 12VDC 5000 0.08 4243 0.33 6.07/61.9 2.72 2.22 42.2/430
2975 6.0~12.0 12VDC 12000 0.29 10165 0.33 5.75/58.6 1.31 8.9 80.4/820
RS-395SH 15130 6.0~12.0 12VDC 3650 0.66 2949 0.25 5.83/59.5 1.8 1.06 30.4/310
15100R 6.0~24.0 24VDC 10300 0.07 8893 0.38 7.09/72.3 6.68 2.66 54.9/560
Recommend Product
Recommend Product Guide
Recommend Model Detail Recommend Model Detail Recommend Model Detail Recommend Model Detail Recommend Model Detail Recommend Model Detail Recommend Model Detail
Feedback

Looking forward to your feedback!

Contact Banner
Frequently Asked Questions
What are the primary applications of these Micro DC Motors?
These RS-380, RS-385, RS-390, and RS-395 micro motors are ideal for high-speed and high-torque tools and models, such as electric drills, garden tools, and toy models.
Can the motor shaft length and performance specifications be customized?
Yes, we support comprehensive customization for motor specifications, including shaft length, operating voltage range, speed, and torque profile to match your specific application requirements.
What is the typical operating voltage range for these motors?
These motors typically operate within a voltage range of 12V to 24V DC, providing flexible power configuration options depending on the chosen model and nominal performance requirement.
How do I choose the correct motor model between the RS-390 and RS-395 series?
You can refer to our Technical Datasheet to compare the rated voltage, no-load speed (RPM), operating ranges, and stall torque values. Different sub-models target different speed-to-torque preferences.
What is the maximum rated speed (RPM) these micro motors can achieve?
Depending on the specific configuration and model, these micro motors can achieve high speeds of up to 12,000 to 13,000 RPM under nominal voltage.
