WICCA Motor
1 / 4
Motor Customized Specification, Please contact us.
The length of shaft can be customized, Please contact us.
| PMDC MOTOR Technical Data | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Model | Rated Voltage(V) | No-Load | Rated | Stall | |||||||
| Operating Range | Nominal | Speed | Current | Speed | Current | Torque | Power | Current | Torque | ||
| RPM | A | RPM | A | mN.m / gf.cm | W | A | mN.m / gf.cm | ||||
| RS-550H | 23128R | 6.0~24.0 | 24VDC | 4500 | 0.1 | 3932 | 0.39 | 25.7/262 | 10.6 | 4.8 | 204/2080 |
| 6034 | 6.0~12.0 | 12VDC | 16000 | 1.12 | 13613 | 4.96 | 25.6/261.3 | 40.36 | 48.89 | 281.4/2870 | |
| RS-555H | 3540 | 6.0~12.0 | 12VDC | 7800 | 0.3 | 6708 | 1.84 | 21.9/223.4 | 15.35 | 11.31 | 156/1591 |
| 23100 | 6.0~24.0 | 24VDC | 7000 | 0.14 | 6004 | 0.77 | 19.2/195.8 | 12.09 | 4.2 | 124.5/1270 | |
We are a factory specializing in producing motors for more than 14 years. A professional R&D team and mature management ensure a satisfying experience.
To guarantee premium quality, every process—from receiving incoming materials to final shipment—is carefully checked at each step. Quality is the core of our development.
A: We are a factory. We have specialized in micro DC motors and DC gear motors for more than 14 years.
A: We can establish an Assurance Order online for new customers, which supports online payment methods such as Visa and MasterCard. Customers can also choose to pay via PayPal or T/T.
A: Yes, we can customize a motor to match your specific requirements and technical parameters.
A: Yes, we have CE, FCC, ISO, and other relevant certificates. If you need any other specific certificates, we can apply for them for you.
A: We deploy professional inspectors on every step of the production line. Once assembly is complete, we perform comprehensive testing using specialized equipment such as Hardness Testers, 2.5D Image Testers, Salt Spray Chambers, Life Testers, Temperature Test Machines, and Noise Testers.
A: Please provide the required operating voltage, rated speed, stall torque, shaft dimensions, and your application space constraints for our technical team to design a suitable solution.
